MVVM Pada Windows Presentation Foundation (WPF)


Menerapkan SVVM Pada WPF



Ubah kode pada MainWindow.xaml menjadi seperti berikut

<Window x:Class="LatihanMVVM.MainWindow"
        xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
        xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
        Title="MainWindow" Height="356" Width="528">

    <Window.Resources>
        <Style TargetType="TextBlock">
            <Setter Property="FontSize" Value="20" />
            <Setter Property="FontFamily" Value="Myriad Pro" />
            <Setter Property="FontWeight" Value="SemiBold" />
            <Setter Property="Background">
                <Setter.Value>
                    <LinearGradientBrush EndPoint="0.5,1" StartPoint="0.5,0">
                        <GradientStop Color="#FF508FC4" Offset="0" />
                        <GradientStop Color="#FF6F94AD" Offset="1" />
                        <GradientStop Color="#FFC7F3FF" Offset="0.302" />
                    </LinearGradientBrush>
                </Setter.Value>
            </Setter>
            <Setter Property="Foreground">
                <Setter.Value>
                    <LinearGradientBrush EndPoint="0.5,1" StartPoint="0.5,0">
                        <GradientStop Color="#FF5252CE" Offset="0" />
                        <GradientStop Color="#FF0000DB" Offset="0.953" />
                        <GradientStop Color="#FF6363CB" Offset="0.337" />
                    </LinearGradientBrush>
                </Setter.Value>
            </Setter>
        </Style>

        <Style TargetType="Label">
            <Setter Property="FontSize" Value="14" />
        </Style>

        <Style TargetType="TextBox">
            <Setter Property="Language" Value="in-IN" />
            <Setter Property="Template">
                <Setter.Value>
                    <ControlTemplate>
                        <Border x:Name="customBorder" Background="{TemplateBinding Background}" CornerRadius="5" BorderThickness="2" BorderBrush="Gray">
                            <ScrollViewer x:Name="PART_ContentHost"/>
                        </Border>
                        <ControlTemplate.Triggers>
                            <Trigger Property="IsKeyboardFocused" Value="True">
                                <Setter TargetName="customBorder" Property="Effect">
                                    <Setter.Value>
                                        <DropShadowEffect BlurRadius="10" ShadowDepth="0" Color="#578EC9"/>
                                    </Setter.Value>
                                </Setter>
                            </Trigger>
                            <Trigger Property="IsKeyboardFocused" Value="False">
                                <Setter Property="Foreground" Value="Gray" />
                            </Trigger>
                        </ControlTemplate.Triggers>
                    </ControlTemplate>
                </Setter.Value>
            </Setter>
        </Style>

        <Style TargetType="Button">
            <Setter Property="Background" Value="#DEF2FC" />
            <Setter Property="Foreground" Value="Black" />
            <Setter Property="FontSize" Value="15"/>
            <Setter Property="Effect">
                <Setter.Value>
                    <DropShadowEffect BlurRadius="10" ShadowDepth="0" Color="#578EC9"/>
                </Setter.Value>
            </Setter>
            <Setter Property="Template">
                <Setter.Value>
                    <ControlTemplate TargetType="{x:Type Button}">
                        <Border x:Name="customBorder" Background="{TemplateBinding Background}" CornerRadius="4" BorderThickness="2" BorderBrush="Gray">
                            <ContentPresenter Content="{TemplateBinding Content}" HorizontalAlignment="Center" />
                        </Border>
                        <ControlTemplate.Triggers>
                            <Trigger Property="IsMouseOver" Value="True">
                                <Setter Property="Background" Value="#2394CC" />
                                <Setter Property="Foreground" Value="White" />
                            </Trigger>
                            <Trigger Property="IsPressed" Value="True">
                                <Setter Property="Effect" Value="{x:Null}" />
                            </Trigger>
                            <Trigger Property="IsEnabled" Value="False">
                                <Setter Property="Effect">
                                    <Setter.Value>
                                        <BlurEffect Radius="3"  />
                                    </Setter.Value>
                                </Setter>
                            </Trigger>
                        </ControlTemplate.Triggers>
                    </ControlTemplate>
                </Setter.Value>
            </Setter>
        </Style>
    </Window.Resources>

    <Grid>
        <Label Content="Nama Barang:" Height="29" HorizontalAlignment="Left" Margin="0,49,0,0" Name="label2" VerticalAlignment="Top" HorizontalContentAlignment="Right" Width="107" />
        <TextBox Height="23" HorizontalAlignment="Stretch" Margin="112,55,12,0" Name="textBox1" VerticalAlignment="Top" />
        <Label Content="Jumlah:" Height="27" HorizontalAlignment="Left" Margin="1,86,0,0" Name="label3" VerticalAlignment="Top" Width="106" HorizontalContentAlignment="Right" />
        <TextBox Height="23" HorizontalAlignment="Left" Margin="113,90,0,0" Name="textBox2" VerticalAlignment="Top" Width="62" />
        <Label Content="Harga:" Height="28" HorizontalAlignment="Left" Margin="12,122,0,0" Name="label4" VerticalAlignment="Top" HorizontalContentAlignment="Right" Width="95" />
        <TextBox Height="23" HorizontalAlignment="Left" Margin="113,127,0,0" Name="textBox3" VerticalAlignment="Top" Width="124" />
        <Button Content="Simpan" Height="27" HorizontalAlignment="Left" Margin="207,228,0,0" Name="button1" VerticalAlignment="Top" Width="82" />
        <Label Content="Diskon (%):" Height="33" HorizontalAlignment="Left" Margin="12,161,0,0" Name="label5" VerticalAlignment="Top" HorizontalContentAlignment="Right" Width="95" />
        <TextBox Height="23" HorizontalAlignment="Left" Margin="113,165,0,0" Name="textBox4" VerticalAlignment="Top" Width="62" />
        <Label Content="Total:" Height="33" HorizontalAlignment="Left" Margin="12,194,0,0" Name="label6" VerticalAlignment="Top" HorizontalContentAlignment="Right" Width="95" />
        <Label Content="Label" Height="28" HorizontalAlignment="Left" Margin="113,194,0,0" Name="label7" VerticalAlignment="Top" Width="402" />
        <TextBlock Height="28" HorizontalAlignment="Stretch" Name="textBlock1" Text="Tambah Item Penjualan" VerticalAlignment="Top" TextAlignment="Center" Margin="0,12,0,0" />

        <Grid.Background>
            <LinearGradientBrush EndPoint="0.5,1" StartPoint="0.5,0">
                <GradientStop Color="#FFB7CEFF" Offset="0.192" />
                <GradientStop Color="White" Offset="1" />
                <GradientStop Color="#FF1648AD" Offset="0" />
            </LinearGradientBrush>
        </Grid.Background>

    </Grid>
</Window>

Buat sebuah model baru dengan nama ItemPenjualan

using System;
using System.Collections.Generic;
using System.Linq;
using System.Text;
using System.ComponentModel.DataAnnotations;
using System.ComponentModel.DataAnnotations.Schema;

namespace LatihanMVVM
{
    public class ItemPenjualan
    {
        public ItemPenjualan()
        {
            DiskonPersen = 0;
        }

        public long Id { get; set; }

        public string NamaBarang { get; set; }

        public int Jumlah { get; set; }

        public decimal Harga { get; set; }

        public decimal DiskonPersen { get; set; }

        public decimal Total()
        {
            decimal total = Jumlah * Harga;
            return total - (DiskonPersen / 100 * total);
        }
    }
}


Buat view model baru dengan nama ItemPenjualanViewModel


using System;
using System.Collections.Generic;
using System.Linq;
using System.Text;
using System.ComponentModel;

namespace LatihanMVVM
{
    class ItemPenjualanViewModel : INotifyPropertyChanged
    {
        public event PropertyChangedEventHandler PropertyChanged;

        private ItemPenjualan model;

        public ItemPenjualanViewModel(ItemPenjualan itemPenjualan = null)
        {
            this.model = itemPenjualan ?? new ItemPenjualan();
        }

        public string NamaBarang
        {
            get { return model.NamaBarang; }
            set
            {
                if (value != model.NamaBarang)
                {
                    model.NamaBarang = value;
                    PropertyChanged(this, new PropertyChangedEventArgs("NamaBarang"));
                }
            }
        }

        public int Jumlah
        {
            get { return model.Jumlah; }
            set
            {
                if (value != model.Jumlah)
                {
                    model.Jumlah = value;
                    PropertyChanged(this, new PropertyChangedEventArgs("Jumlah"));
                    PropertyChanged(this, new PropertyChangedEventArgs("Total"));
                }
            }
        }

        public decimal Harga
        {
            get { return model.Harga; }
            set
            {
                if (value != model.Harga)
                {
                    model.Harga = value;
                    PropertyChanged(this, new PropertyChangedEventArgs("Harga"));
                    PropertyChanged(this, new PropertyChangedEventArgs("Total"));
                }
            }
        }

        public decimal DiskonPersen
        {
            get { return model.DiskonPersen; }
            set
            {
                if (value != model.DiskonPersen)
                {
                    model.DiskonPersen = value;
                    PropertyChanged(this, new PropertyChangedEventArgs("DiskonPersen"));
                    PropertyChanged(this, new PropertyChangedEventArgs("Total"));
                }
            }
        }

        public string Total
        {
            get
            {
                decimal? total = model.Total();
                if (!total.HasValue)
                {
                    return "-";
                }
                else
                {
                    return total.Value.ToString("C");
                }
            }
        }

        public ItemPenjualan Model
        {
            get { return this.model; }
        }
    }
}
